QMS

Ritec Machinery Quality Management System


"Quality First, Customer First", starting from the actual needs of customers, providing customers with high-quality products and helping customers to use products better has always been Ritec's philosophy and purpose. For this reason, Ritec has established strict quality management. The system ensures that every process of each machine produced by Ritec will not be omitted, including the selection of raw materials, casting, forging, welding, machining, assembly, appearance, testing and other steps in accordance with industry standards and company standards Production and inspection. Ensure strict quality control of all aspects of machine tool production. Let customers receive satisfactory products!

Quality Inspection


The parts used in machine production are all processed by Ritec's workshop. Ritec has set up a professional quality inspection team to inspect all processed parts one by one. The company has a variety of testing equipment, including laser interferometers, balancers, and tool setting instruments. After each machine is assembled, it is strictly required to carry out no-load running test, load running test, geometric accuracy inspection and working accuracy inspection.

  • Dial indicator to inspect the straightness of the guide rail.
    Guide Rail Inspection
    Dial indicator to inspect the straightness of the guide rail.
  • Measuring and calibrating positioning accuracy with a Renishaw laser interferometer.
    Renishaw Laser Interferometer
    Measuring and calibrating positioning accuracy with a Renishaw laser interferometer.
  • After tool setting, the offset value of the tool to the workpiece coordinate system can be automatically set, so that the workpiece coordinate system can be automatically established.
    Tool Setting Instrument
    After tool setting, the offset value of the tool to the workpiece coordinate system can be automatically set, so that the workpiece coordinate system can be automatically established.
  • The Ritec workshop is equipped with a three-axis coordinate measuring instrument to complete tasks such as parts inspection, appearance measurement, and process control.
    Three Coordinate Measuring Instrument
    The Ritec workshop is equipped with a three-axis coordinate measuring instrument to complete tasks such as parts inspection, appearance measurement, and process control.

Manufacturing Process


The assembly process of the machine will also affect the customer's feelings when using the machine. Therefore, Ritec strictly follows the quality management standards from the most basic machine bed to the final assembly of the whole machine during the machine assembly process.

  • Steel plates, round steels, square steels, profiles, etc. required in production are purchased by professional purchasing personnel in strict accordance with technical requirements.
    Selection of Raw Materials
    Steel plates, round steels, square steels, profiles, etc. required in production are purchased by professional purchasing personnel in strict accordance with technical requirements.
  • Strict quality inspection of all welded parts. Only the welded parts that pass the inspection can enter the next process. After welding, artificial aging treatment and heat treatment procedures are required to ensure the accuracy and stability of the CNC machine.
    Welding
    Strict quality inspection of all welded parts. Only the welded parts that pass the inspection can enter the next process. After welding, artificial aging treatment and heat treatment procedures are required to ensure the accuracy and stability of the CNC machine.
  • Equipped with large-scale powder painting equipment, the paint surface is fuller, uniform and shiny
    Powder Painting
    Equipped with large-scale powder painting equipment, the paint surface is fuller, uniform and shiny
  • Assembly workers with more than 6 years of work experience and strict assembly process and assembly sequence to ensure the realization of assembly process requirements
    Assemble
    Assembly workers with more than 6 years of work experience and strict assembly process and assembly sequence to ensure the realization of assembly process requirements

Pre-delivery Inspection


Ritec machines will undergo a number of quality inspections, including performance, stability, adaptability, and practicability. The parts that do not meet the standards will be debugged and repaired to ensure that the machine is in the best condition before leaving the factory.

  • In order to verify the entered machining program, a load-free running test is carried out after the cnc machine is assembled
    Load-Free Test
    In order to verify the entered machining program, a load-free running test is carried out after the cnc machine is assembled
  • Before delivery, we will process different materials according to customer needs, check the processing effect, and then adjust as needed
    Processing Test
    Before delivery, we will process different materials according to customer needs, check the processing effect, and then adjust as needed
  • After the CNC machine tool is assembled, we will clean it to ensure that the machine is delivered to you perfectly
    Cleaning Machine
    After the CNC machine tool is assembled, we will clean it to ensure that the machine is delivered to you perfectly
  • CNC equipment needs multiple protective measures during packaging to ensure that each part is not affected by collision
    Machine Packing
    CNC equipment needs multiple protective measures during packaging to ensure that each part is not affected by collision
